Modular interactive input system

#include <esp_now.h>
#include <WiFi.h>


int touchAngle;              // variable to store servo angle in for the touch input to revolution angle
int squeezeSensorPin1 = A9;  // Squeeze sensor pin > up/down
int soundSensorPin2 = A10;   // Sound sensor pin > sweep
int buttonPin = D6;
#define NUM_TOUCH_PINS 7

int touchPins[NUM_TOUCH_PINS] = { T1, T2, T3, T4, T5, T6, T7 };
int touchThresholds[NUM_TOUCH_PINS] = { 110000, 110000, 110000, 110000, 110000, 110000, 110000 };
int mappedValues[13];  // Precompute the 13 values between 0 and 180

int sensorData1 = 0;
int sensorData2 = 0;

// Keeps track of the last pins touched
// so we know when buttons are 'released'
uint16_t lasttouched = 0;
uint16_t currtouched = 0;

// REPLACE WITH YOUR RECEIVER MAC Address: 64:e8:33:00:90:1c
uint8_t broadcastAddress[] = { 0x64, 0xe8, 0x33, 0x00, 0x90, 0x1c };

// Structure example to send data
// Must match the receiver structure
typedef struct struct_message {
  int id;  // must be unique for each sender board
  int revolution;
  int pressure;
  int sweep;
  int ink;
} struct_message;

// Create a struct_message called myData
struct_message myData;

esp_now_peer_info_t peerInfo;

// callback when data is sent
void OnDataSent(const uint8_t *mac_addr, esp_now_send_status_t status) {
  Serial.print("\r\nLast Packet Send Status:\t");
  Serial.println(status == ESP_NOW_SEND_SUCCESS ? "Delivery Success" : "Delivery Fail");
}

void setup() {
  // Init Serial Monitor
  Serial.begin(115200);
pinMode(buttonPin, INPUT_PULLUP);
  // Set device as a Wi-Fi Station
  WiFi.mode(WIFI_STA);

  // Init ESP-NOW
  if (esp_now_init() != ESP_OK) {
    Serial.println("Error initializing ESP-NOW");
    return;
  }

  // Once ESPNow is successfully Init, we will register for Send CB to
  // get the status of Transmitted packet
  esp_now_register_send_cb(OnDataSent);

  // Register peer
  memcpy(peerInfo.peer_addr, broadcastAddress, 6);
  peerInfo.channel = 0;
  peerInfo.encrypt = false;

  // Add peer
  if (esp_now_add_peer(&peerInfo) != ESP_OK) {
    Serial.println("Failed to add peer");
    return;
  }
}

void loop() {
  touchAngle = getTouchAngle();  // Call the function to update touchAngle
  if (touchAngle != -1) {
    Serial.println(touchAngle);  // Print the touchAngle to Serial Monitor
  }

  sensorData1 = analogRead(squeezeSensorPin1);
  sensorData2 = analogRead(soundSensorPin2);

  // Set values to send
  myData.id = 1;           // board number in case there will be more boards sending later
  myData.revolution = touchAngle;   // 0-180
  myData.pressure = sensorData1;  // 0-4095
  myData.sweep = sensorData2;  // 0-4095
  myData.ink = digitalRead(buttonPin);  // 0-1

  Serial.println(touchAngle);
  Serial.println(sensorData1);
  Serial.println(sensorData2);
  Serial.println(digitalRead(buttonPin));

  // Send message via ESP-NOW
  esp_err_t result = esp_now_send(broadcastAddress, (uint8_t *)&myData, sizeof(myData));

  if (result == ESP_OK) {
    Serial.println("Sent with success");
  } else {
    Serial.println("Error sending the data");
  }
  delay(50);
}

// determine if touch pins are touched and map to servo motor angle 0-180

int getTouchAngle() {
  int activePin = -1;
  int nextPin = -1;

  // Check which pin(s) are touched
  for (int i = 0; i < NUM_TOUCH_PINS; i++) {
    int touchValue = touchRead(touchPins[i]);
    if (touchValue > touchThresholds[i]) {
      if (activePin == -1) {
        activePin = i;
      } else {
        nextPin = i;
        break;  // We found two adjacent touches
      }
    }
  }

  if (activePin != -1) {
    if (nextPin != -1 && nextPin == activePin + 1) {
      // Calculate interpolated value between activePin and nextPin
      int interpolatedValue = map(activePin, 0, NUM_TOUCH_PINS - 1, 0, 180);
      int nextInterpolatedValue = map(nextPin, 0, NUM_TOUCH_PINS - 1, 0, 180);
      return (interpolatedValue + nextInterpolatedValue) / 2;
    } else {
      // Return mapped value for single touch
      return map(activePin, 0, NUM_TOUCH_PINS - 1, 0, 180);
    }
  }

  return -1;  // No touch detected
}
